AMF PANEL/BOX 100/200KVA 380V - 24 VOLT
R21 950,00 ex. VAT R25 242,50 inc. VAT
Product Code: AMF003
Request a quote for "AMF PANEL/BOX 100/200KVA 380V - 24 VOLT"
* indicates a required field
Free Call Back for "AMF PANEL/BOX 100/200KVA 380V - 24 VOLT"
* indicates a required field
After Sales Support for "AMF PANEL/BOX 100/200KVA 380V - 24 VOLT"
* indicates a required field
Operators Manual for "AMF PANEL/BOX 100/200KVA 380V - 24 VOLT"
* indicates a required field
Spares For "AMF PANEL/BOX 100/200KVA 380V - 24 VOLT"
* indicates a required field
Request a demo for "AMF PANEL/BOX 100/200KVA 380V - 24 VOLT"
* indicates a required field
Manage high-capacity power effortlessly with this 100/200 kVA 380V AMF Panel/Box. Designed for heavy-duty generator control, it ensures reliable automatic switching, system protection, and stable energy supply when used with our 100 to 200KVA gensets. . Compatible with 24V setups, it’s perfect for industries requiring continuous and safe power backup.
DISPLAY FUNCTIONS
Line Voltage Display
Phase Voltage Display
Frequency Display Hz
Load Current Display
Active Power Display kW
Apparent Power Display kVA
Temperature Display Celsius and Fahrenheit
Oil Pressure Display kPa psi bar
Fuel Level Display Percentage
Engine Speed Display RPM
Battery Charge Voltage Display
PROTECTION AND CONTROL FUNCTIONS
Over Voltage Protection
Under Voltage Protection
Over Frequency Protection
Under Frequency Protection
Over Current Protection
Automatic Start and Stop Control
Automatic Transfer Switch ATS Compatible
Failure Alarm Display and System Protection
Emergency Stop Switch
Start Method Key Start
ELECTRICAL
Rated Voltage: 380V
Power Output Range: 100 kVA to 200 kVA
Phase: 3 Phase
Control Voltage: 24V
DIMENSIONS
Length: 550 mm
Width: 480 mm
Height: 1250 mm
